| Oversized | No |
| Heavy Duty Supplier | Yes |
| Bore (Inch) | 3.6614 |
| Note 2 | Single Piston |
| Pin Type | P |
| Assembly Lubricant Included | No |
| Note 1 | Standard Size |
| Ring 1 Qty | 2 |
| Top Compression Ring Thickness | 1.50 |
| Standard Size | Standard |
| Ring 2 Width | 3.00mm |
| Cylinder Bore Diameter | 3.6614 |
| Head Type | Flat Head; DUROSHIELD~ skirt coated piston |
| Bore (MM) | 93.0000 |
| Pin Diameter (Inch) | 0.9014 |
| Part Description | Engine Piston |
| Minimum Clearance | See Piston Fitting Information on carton label |
| Package Alert | Single Piston |
| Part Material | Cast |
| Oil Ring Thickness | 3.00 |
| Pin Offset (MM) | 1.524 |
| Piston Pin Outside Diameter | 22.896 |
| Second Compression Ring Thickness | 1.50 |
| Pin Diameter (MM) | 22.896 |
| Compression Distance | 1.167 |
| Piston Material | Cast Aluminum |
| Pin Offset (Inch) | 0.06 |
| Ring 2 Qty | 1 |
| Head Illustration | 23 |
| Ring 1 Width | 1.50mm |
| Part Terminology | Engine Piston |
