| Pin Diameter (Inch) | 0.75 |
| Package Alert | Single Piston |
| Minimum Clearance | 0.001 @ .350 from bottom of skirt |
| Oversize Inch | 0.080 |
| Heavy Duty Supplier | Yes |
| Part Material | Cast |
| Bore (Inch) | 3.1875 |
| Note 2 | Single Piston |
| Pin Offset (MM) | 1.524 |
| Ring 1 Qty | 2 |
| Note 1 | Oversize Inch .080 |
| Compression Distance | 1.519 plus .210 crown |
| Pin Diameter (MM) | 19.05 |
| Ring 2 Width | 3/16 |
| Head Type | Crowned Head w/ring below pin - 7.0:1 C.R.; Not factory duplicate; Repl. O.E. No. 8BA-6108A |
| Bore (MM) | 81.0000 |
| Ring 2 Qty | 2 |
| Pin Offset (Inch) | 0.06 |
| Ring 1 Width | 3/32 |
| Head Illustration | 15 |
| Part Terminology | Engine Piston |
