| Piston Head Type | Flat Head |
| Oversized | Yes |
| Heavy Duty Supplier | Yes |
| Bore (Inch) | 3.5625 |
| Bore Diameter | 3.5625 |
| Assembly Lubricant Included | No |
| Ring 1 Qty | 2 |
| Note 1 | Oversize Inch .080 |
| Top Compression Ring Thickness | 0.09375 |
| Ring 2 Width | 3/16 |
| Head Type | Flat Head |
| Bore (MM) | 90.5000 |
| Oversized Amount | 0.080 |
| Pin Diameter (Inch) | 0.865 |
| Part Description | Engine Piston |
| Minimum Clearance | 0.001 @ bottom of skirt |
| Oversize Inch | 0.080 |
| Part Material | Cast |
| Oil Ring Thickness | 0.1875 |
| Pin Offset (MM) | 1.981 |
| Piston Pin Outside Diameter | 0.865 |
| Second Compression Ring Thickness | 0.09375 |
| Piston Pin Inside Diameter | 21.971 |
| Pin Diameter (MM) | 21.971 |
| Compression Distance | 2.062 |
| Ring Material | Cast |
| Prop 65 Label (Yes/No) | No |
| Piston Material | Cast Aluminum |
| Pin Offset (Inch) | 0.078 |
| Ring 2 Qty | 1 |
| Grade Type | Premium |
| Ring 1 Width | 3/32 |
| Head Illustration | 23 |
| Part Terminology | Engine Piston Set |
