Hydraulic
Part # 3204-5675 | Line Code: 142
brandNameImage
brandNameImage

$1,021.22
$1,021.22
error
Not Fitted

Product Details
expand_less
Burst Pressure 900
Dash Size 12
Heavy Duty Supplier Yes
Hose Inside Diameter (in) .75
Coupling Recommendation GLX, Power Crimp
Hose Outside Diameter (mm) 29.2
Length (ft) 50
Inside Diameter .75
Minimum Burst Pressure (psi) 900
Cover Material Synthetic Rubber - EPDM - Type P
Reinforcement Synthetic, High Tensil Textile Cord
Inside Diameter (MM) 19.1
Maximum Working Pressure (psi) 300
Hose Material EPDM - Type P
Industrial Description 3/4X50FT PLANT MASTER 300 RED
Temperature Rating -40 Deg. F ro +200 Deg. F (-40 Deg. C to +93 Deg. C)
Cover Color Red
Minimum Bend Radius (in) 6
Inside Diameter (in) .75
Hose Inside Diameter (mm) 19.1
Maximum Working Pressure 300
Color Red
Vacuum (inHg) 15
Bending Radius 6
Tube Description Black, Limited Oil-Resistant, Synthetic Rubber
Type Plant Master 300
Tube Material EPDM - Type P
Hose Outside Diameter (in) 1.15
Length 50
Outside Diameter (MM) 29.2
Product Type Plant Master 300
Outside Diameter (In) 1.15
Temperature Range -40 Deg. F ro +200 Deg. F (-40 Deg. C to +93 Deg. C)
Cover Type Type P - Limited Oil-Resistant
Outside Diameter 1.15
Maximum Working Pressure (Bar) 20.7
Reinforced Synthetic, High Tensil Textile Cord
Part Terminology Multi-Purpose Hose

Features & Benefits
expand_more
Recommended for air and water applications requiring maximum flexibility in any industry, including mining, construction, agriculture, vehicle repair and in-plant operations.
