| Performance Rated? | Yes |
| Fan Bolt Circle IN | 3.250 |
| Flange Cir. | 1.44 [36mm] HEX |
| Fan Mount Dia. | 2.62 |
| Wire Quantity | Uses Original Equipment Connector |
| Description | Fan Clutches |
| Pilot Diameter | M30 X 1.5 Right |
| Heavy Duty Supplier | Yes |
| Fan Bolt Circle MM | 82.6 |
| Overall Diameter | 7.40 |
| New or Reman | New |
| Mounting Hardware? | Not Included |
| Overall Height MM | 94.5 |
| Pilot Depth MM | 17.8 |
| Fan Bolt Circle | 3.25 |
| Mount Type | HEX |
| Bolt Quantity | 4 |
| Overall Height IN | 3.71875 |
| Pilot Depth IN | 0.703125 |
| Style | Heavy Duty |
| Clutch Type | D - Severe Duty and Truck Fan Drive |
| Drawing Type | D |
| Overall Dia. MM | 188 |
| O.E. Replacement? | Yes |
| Mount Dia. IN | 1.44 [36mm] HEX |
| Pilot Dia. IN | M30x1.500 |
| Original Equipment Replacement? | Yes |
| Duty Rating | Heavy |
| Overall Dia. IN | 7.400 |
| Color | Raw Aluminum in Color |
| Bolt Nut Type | 5/16-18 HOLE (4) |
| Material | Aluminum |
| Wire Guage | Uses Original Equipment Connector |
| Fan Mount Height | 1.21 |
| Mount Dia. MM | 36 HEX |
| Rotation | REV |
| Meets / Exceeds OEM? | Yes |
| Pilot Depth | 0.70 |
| Meets or Exceeds OEM Specs? | Yes |
| Type | Thermal |
| Fan Mount Height IN | 1.203125 |
| Bolt Thread | 5/16-18 Hole |
| Fan Mount Height MM | 30.7 |
| Overall Height (H) | 3.72 |
| Fan Mount Dia. IN | 2.620 |
| Electronic Clutch? | Non Electronic |
| Mount Hole Qty | 4 |
| Fan Mount Dia. MM | 66.5 |
| Part Terminology | Engine Cooling Fan Clutch |
